1K UV-Primer
Product image for Primer / Primer Filler
Primer / Primer Filler

1K UV-Primer

Highly efficient, high-yield and fast-drying semi-transparent 1K UV primer. For the quick repair of minor damage in bodyshops, also suitable for industry and crafts.
Can be dried with most commercially available LED UV lamps in one minute and can be sanded immediately after curing. Hardens at a UV-A light wavelength of 395 nm. SprayMax UV paint repair is a harmonized product system in regarding to application process and coating properties, consisting of:

UV Primer Part no 3680024
UV Clearcoat Part no 3680059
UV BlenderThinner Part no 3680091

More information

Advantages

  • Very fast curing process
  • Short flash-off times
  • Excellent adhesion and good corrosion resistance
  • Very good sandability
  • Suitable for quick small damage repairs (spot repair)

Part information & datasheets

Part No. Color Size Technical data sheet Safety data sheet
3680024 slightly grey, semi-transparent TDS (3680024, EN)
TDS (3680024, ES)
SDS (3680024, EN)
SDS (3680024, ES)

Application notes

Icon Spray distance / spray coats combination
Spray distance / spray coats combination
6 - 10 inches / 15 - 25 cm With approx. 2 spray coats 3.2 - 4.0 (80 - 100 μm) approx. 30 sec. between the spray coats to achieve good curing.
Icon Flash-off time
Flash-off time
Final flash-off time before UV drying: approx. 90 sec.
Icon Drying
Drying
TG5 ready for assembly: after 1 - 2 min. Cured with an UV lamp at distance of 10 - 15 cm
Icon Yield
Yield
Approx. 10.70 sq ft (1 m²) at 3.2 mil (80 μm) dry film thickness

Product information
